Saturday,19-November-2022

Mitsubishi M700 and Servo Mitsubishi MDS-D alarm fix

EN
That is topic dedicated to alarms and trouble codes in Mitsubishi M700 control , caused by defective servo module MDS-D and low backup memory battery.
Most of that MDS-D servo units have own backup battery to keep some settings “alive”. But in my case there was common block as that one:


Getting old and bad, the battery cause constant lose of absolute axis points. So, how that can be that issue fixed ans so on please read below :) [Read More…]

Thursday, 3-November-2022

DMU50 with TNC640 - how to configure CELOS timers and counters

EN

Did you have DMG Mori DMU50 machine with HEIDENHAIN TNC640 which also get as addition CELOS system? Yes?!
But have you wonder how to make both timer lines and numbers to start “doing” their magic?
I mean both marked with arrow below:


So, then that short article is for you. [Read More…]

Saturday,22-October-2022

BOOM BOX 2 - custom made Bluetooth Speaker - NEW verson

EN
Somewhere in the list of topics in my website, I already show one self made battery driven Bluetooth Speaker with proper size.
Well, now is the time to to extend that a bit, and the new build use already two batteries, bigger amplifier and bigger speakers.
The amplifier, once again Chinese and use Bluetooth / 3.5mm jack as input source. The difference with previous one is the missing of SD card / USB reader.
The amplifier itself is based on TDA7498E chip and on paper it will be able to output about 150W@4ohm with 36V of power supply. The bridged mode will be of about 200W.. That is quite a lot for such a small foot print chip but let`s see.
[Read More…]

Sunday, 9-October-2022

Sinumerik 840D - extend tool list by parameter

EN

Before you continue or try what is described in this topic, be advised - I`m not held responsible if something goes wrong!
It is fully your choice. And if you have no idea what are you doing, please do not try it.

Have you notice how many tools you can add in the list? In my test it was about 200. Never reach that point but what about looking at few parameters.
Steps are as follow:
[Read More…]

KIA Ceed front breaks replace

EN

Replacing front breaks is not some space science , and same apply also here. Nothing fancy, nothing spacial.
The tools you need are:
- 14mm socket (for the moving hub)
- 17mm socket (caliper`s holder)
- 17mm spanner
- some WD40 , steel brush, impact screw driver, torque wrench, copper grease…
[Read More…]

Monday, 4-July-2022

KIA Ceed 2009 - AUX port issues / fix and how to remove

EN
In that topic will present to you some solution to a case, which some of you may drop on. The AUX port just snap.
One option is to replace only the port (in my case), or just the whole board. In AliExpress that cost about 15e / 18$ , but despite what plan is , here is how you remove all plastics so you can reach the clips, which keep the port holder.
[Read More…]

Friday, 1-July-2022

BOOM BOX - custom made Bluetooth Speaker

EN
There are many ways to build own Bluetooth custom speaker box, and here in that article is my first attempt.
Used in the project:
- MDF 6 and 9mm
- full range speakers: 50mm@15W, twiters: 2cm@3W, bass: 9cm@35W
- amplifier , Milwaukee M18 battery holder, some wires …
- fun…
[Read More…]

Monday, 4-April-2022

DMG Celos - some small tip

EN
In this topic, will try to give some tips how you can access the Windows 10 part of CELOS user interface used in DMG mori machines along side of Haidenhain NC.
What I mean? If you poke around, probably you already know that there is VNC “remote” access to the Windows 10 computer build in some DMG Mori machines, which control the CELOS side. Yes, but that one has password that they probably didn`t give you.
For me, it was more annoying that the clock on that Windows machine was way off from the TNC640 one. So what now?
[Read More…]

Sunday, 7-November-2021

KIA Ceed - multimedia/maps update - for LG LAN2060EKJD

EN
In that topic will show you how I did update my car`s multimedia system to newest maps and software possible for now. In some websites there are offers that for about 40e / 30£ they will send you download link.. Why should I do that?

Before even start, keep in mind two really important things: that will take quite some time (the actual USB to car transfer) . Maybe about 30-35min at least, and also the engine must run or connect some battery charger so that the car will not go into Energy saving mode. Actually, if you have some long trip, plug the flash drive, select until the process start and you do not need to touch anything anymore and drive. The player will continue to play radio station what you left and meanwhile update.

The PLAYER in question is LG LAN2060EKJD , belong to KIA Ceed model `2014, and it look like that (image on right) radio.jpg

[Read More…]

Friday,13-August-2021

Ford S-MAX Cabin fan & controller replacement

EN

In that case, the car just in one night “sleep” went from full normal operational mode into no fan situation.
The motor control was suspected, and actually cause the malfunction.
In few words, the automatic A/C system control unit drive the fan speed via strong, cooled transistors. Nothing so unusual here. And what might be in the magic box? well… that one:

s_max_blow_12.jpg s_max_blow_11.jpg

[Read More…]
